Overview
Introducing the Team Associated TC28 Team Kit - a compact, precision-engineered 1/28 scale on-road race car designed with the same engineering excellence found in every AREA 51-developed product. Though small in scale, the TC28 delivers big performance in an easy-to-tune package that's perfect for competitive racing in tight spaces.
Featuring independent front and rear suspension, constant velocity driveshafts, mid-motor configuration with equal length belts, and fluid-filled gear differentials, the TC28 is built for high performance. The steel chassis plate provides a low center of gravity while adjustable roll center inserts enable chassis roll adjustment based on grip levels.
Key Features
- Steel chassis plate for low center of gravity
- Independent suspension front and rear
- Mid-motor configuration with equal length belts
- Fluid-filled gear differentials with height and belt tension adjustment
- Front and rear anti-roll bar system
- Silicone grease lubricated shocks
- Constant velocity driveshafts
- Insert adjustable roll center
- Compatible with all 28th scale Reedy electronics
Performance Benefits
- Balanced power delivery with equal length belts
- Excellent handling and responsiveness
- Highly tunable for various track conditions
- Low CG design for improved stability
- Smooth, consistent differential action
Usage Notes
- Perfect for 1/28 scale on-road racing
- Ideal for indoor carpet and small-space tracks
- Recommended for intermediate to advanced builders
- Compatible with Reedy 28th scale electronics
Technical Specs
- Scale: 1:28
- Drive: 4WD (Belt-driven)
- Length: 140mm (5.51")
- Wheelbase: 98mm (3.86")
- Power: 2S LiPo compatible
- Differentials: Fluid-filled gear type
What's Included
- TC28 1/28 4WD On-Road Team Kit
- RadBody Mako X2 Body (Clear)
- White Wheels (4)
- Assembly hardware and instructions
Needed to Complete
- 2-Channel Radio System
- Micro Steering Servo (Reedy RS0305A recommended)
- Micro ESC & Motor (Reedy Blackbox 300R & Sonic 1525 recommended)
- 2S (7.4V) LiPo Battery Pack (Reedy 400mAh 60C recommended)
- Compatible Charger
- Tires
- Tools for Assembly
- Polycarbonate Paint
Summary
The Team Associated TC28 Team Kit brings championship-level engineering to the 1/28 scale class. Compact, tunable, and race-ready, it's built for serious on-road competition in any environment.
