Overview
The Team Associated RC10B84 is a championship-caliber 1/10 scale 4WD electric buggy engineered for precision, speed, and racetrack dominance. Designed specifically for carpet, AstroTurf, and high-grip indoor racing surfaces, this competition machine delivers superior handling and control that serious racers demand. Every element has been optimized for podium finishes, from its innovative height-adjustable gearboxes to its long-arm suspension geometry that enhances grip and predictability.
At the heart of this race-ready platform are molded height-adjustable gearboxes that keep weight low while providing a wide range of adjustability. The optimized steering bellcranks and rack provide exceptional bump steer control, keeping your racing lines tight through every corner. Fine-tune your setup with chassis bracing adjustments, giving you the flexibility to adapt to each track you race on while pushing the limits with confidence.
Key Features
- Molded height-adjustable gearboxes front and rear for optimal weight placement
- Additional +2 rear gearbox included for high-grip conditions
- Long-arm suspension geometry improves grip and predictability
- Optimized steering bellcranks and rack for reduced bump steer
- Adjustable chassis bracing front and rear for fine-tuning flex characteristics
- Standard and HRC (High Roll Center) rear hubs included
- Insert-adjustable caster blocks (0, +/-1, +/-2 degree inserts)
- Forward and back motor positions for weight bias adjustment
- 2.5mm thick tapered 7075-T6 aluminum chassis with 10° kickup
- Decoupled slipper clutch for smooth power delivery
- 13mm big-bore shocks with shock tower covers
- 7-inch rear wing with two mount height options
- Low-profile aerodynamic body design
Performance Benefits
- True 4WD drivetrain delivers maximum traction on high-grip surfaces
- Height-adjustable gearboxes optimize efficiency for carpet and clay racing
- Long-arm suspension maximizes corner speed and stability
- Reduced bump steer enables tighter, more consistent racing lines
- Decoupled slipper provides smooth, controllable power transfer
- Tunable chassis flex characteristics via adjustable bracing
- Enhanced aerodynamics with low-profile body design
- Improved departure angle for aggressive jumping
Usage Notes
The RC10B84 Team Kit is designed for competitive 4WD buggy racing on carpet, AstroTurf, and high-grip sealed clay surfaces. This kit requires assembly and electronics selection, ideal for intermediate-to-advanced racers competing at club through national levels. Best suited for indoor racing environments where grip is consistent and high.
Technical Specs
-
Scale: 1/10
-
Drivetrain: 4WD
-
Length: 395mm (15.55 in)
-
Chassis: 2.5mm 7075-T6 Aluminum with 10° Kickup
-
Shocks: 13mm Big-Bore
-
Battery: 2S LiPo Shorty
-
Surface: Carpet, AstroTurf, High-Grip Clay
-
Format: Team Kit (Unassembled)
-
Brand: Team Associated
What's Included
- RC10B84 1/10 scale 4WD buggy kit (unassembled)
- 2.5mm 7075-T6 aluminum chassis
- Molded height-adjustable gearboxes (front, rear, +2 rear)
- 13mm big-bore aluminum shocks
- Shock tower covers front and rear
- Standard and HRC rear hubs
- Insert-adjustable caster blocks with all inserts
- Low-profile polycarbonate body (clear)
- 7-inch rear wing with dual mount heights
- 3.5mm turnbuckles and ball cups
- Decal sheet and instruction manual
Needed to Complete
- 2-channel radio system (transmitter and receiver)
- Steering servo
- Electronic Speed Controller (ESC)
- 540-size brushless motor and pinion gear
- 2S LiPo shorty battery
- Compatible battery charger
- 1/10 off-road wheels and tires
- Polycarbonate body paint
- Silicone shock and diff fluids
- Assembly tools
Summary
The Team Associated RC10B84 Team Kit delivers championship-level 4WD buggy performance optimized for carpet and high-grip racing. With height-adjustable gearboxes, long-arm suspension, decoupled slipper clutch, and extensive tunability, this race machine provides the speed, grip, and precision serious competitors demand for podium finishes.
