Overview
The Team Associated RC10B84D is a championship-caliber 1/10 scale 4WD off-road electric buggy engineered for victory on dirt, clay, and low-grip surfaces. This next-generation race machine delivers the perfect balance of speed, control, and adjustability that serious competitors demand. From its innovative height-adjustable gearboxes to its long-arm suspension geometry, every element has been optimized for podium-finishing performance on today's most demanding dirt tracks.
Designed with cutting-edge features by Team Associated's Area 51 engineering team, the RC10B84D provides superior handling and control through its molded height-adjustable gearboxes that keep weight low while offering a wide range of tuning options. The optimized steering bellcranks and rack provide exceptional bump steer control, keeping your racing lines tight through every corner. Fine-tune your setup with adjustable chassis bracing front and rear, giving you the flexibility to adapt to each track's unique characteristics.
Key Features
- Molded height-adjustable gearboxes front and rear
- Additional +2 rear gearbox included for high-grip conditions
- Long-arm suspension geometry for improved grip and predictability
- Optimized steering bellcranks and rack for reduced bump steer
- Adjustable upper and lower chassis bracing front and rear
- Standard and HRC (High Roll Center) rear hubs included
- Insert-adjustable caster blocks with 0, +/-1, +/-2 degree inserts
- Forward and back motor positions for weight bias adjustment
- Highly adjustable battery holder with thumb tabs
- 2.5mm thick tapered 7075-T6 aluminum chassis with 10° kickup
- Molded ring and pinion gears included
- Aluminum center-mounted servo mount
- Two rear wing mount heights included
- 7-inch rear wing with low-profile body
- 13mm big-bore shocks with shock tower covers
- 3.5mm turnbuckles and ball cups
Performance Benefits
- Height-adjustable gearboxes optimize drivetrain efficiency for any track
- Long-arm suspension maximizes grip and corner speed on dirt
- Reduced bump steer delivers tighter, more consistent racing lines
- Adjustable chassis bracing fine-tunes flex characteristics
- Motor position options enable precise weight bias tuning
- 10° chassis kickup improves departure angle for aggressive jumps
- Low-profile body enhances aerodynamics at high speeds
- Big-bore shocks provide consistent damping performance
Dirt Racing Optimization
- Designed specifically for dirt, clay, and low-grip surfaces
- Ball differential setup for dirt-specific power delivery
- HRC rear hubs included for varied roll center tuning
- Multiple caster block inserts for steering feel adjustment
- +2 rear gearbox adapts to changing track conditions
Usage Notes
The RC10B84D Team Kit is designed for competitive 1/10 4WD off-road buggy racing on dirt, clay, and low-grip surfaces. This kit requires assembly and racer-selected electronics. Ideal for club-level through national-level competition. The "D" designation indicates dirt-optimized setup and components.
Technical Specs
-
Scale: 1/10
-
Drivetrain: 4WD
-
Length: 395mm (15.55 in)
-
Chassis: 2.5mm 7075-T6 Aluminum with 10° Kickup
-
Shocks: 13mm Big-Bore
-
Battery: 2S LiPo Shorty
-
Surface: Dirt, Clay, Low-Grip
-
Format: Team Kit (Unassembled)
-
Brand: Team Associated
What's Included
- RC10B84D 1/10 4WD buggy kit (unassembled)
- 2.5mm 7075-T6 aluminum chassis
- Height-adjustable gearboxes (front, rear, +2 rear)
- 13mm big-bore aluminum shocks
- Shock tower covers front and rear
- Standard and HRC rear hubs
- Insert-adjustable caster blocks with all inserts
- Low-profile polycarbonate body (clear)
- 7-inch rear wing with dual mount heights
- Decal sheet
- Assembly hardware and instruction manual
Needed to Complete
- 2-channel radio system (transmitter and receiver)
- Steering servo
- Electronic Speed Controller (ESC)
- 540-size electric motor
- Pinion gear
- 2S LiPo shorty battery
- Compatible battery charger
- 1/10 off-road wheels and tires
- Polycarbonate body paint
- Silicone shock and diff fluids
- Assembly tools
Summary
The Team Associated RC10B84D is engineered for victory on dirt and low-grip surfaces. With its innovative height-adjustable gearboxes, long-arm suspension geometry, and comprehensive tuning options, this 1/10 4WD buggy delivers championship-caliber performance for serious racers. The precision engineering from Area 51 ensures you have every advantage needed to reach the podium.
