Overview
The Team Associated RC10B84D Classic Kit unleashes championship-level 4WD buggy performance with iconic RC10 heritage styling. This limited edition 1/10 scale electric buggy is engineered for precision, speed, and racetrack victories, combining cutting-edge race technology with classic-inspired livery, premium composite plastics, and aluminum components. Designed specifically for dirt and low-grip track conditions, the RC10B84D Classic delivers superior handling and control that serious racers demand.
At the heart of this competition machine are molded height-adjustable gearboxes that optimize drivetrain efficiency for varying grip levels. The long-arm suspension geometry enhances grip and predictability, while optimized steering bellcranks and rack provide exceptional bump steer control, keeping your racing lines tight through every corner. Fine-tune your setup with adjustable chassis bracing, allowing precise weight distribution and chassis balance for maximum confidence at the limit.
Key Features
- Molded height-adjustable gearboxes front and rear
- Additional +2 rear gearbox for high-grip conditions included
- Long-arm suspension geometry for improved grip and predictability
- Optimized steering bellcranks and rack for reduced bump steer
- Adjustable upper and lower chassis bracing front and rear
- Standard and HRC (High Roll Center) rear hubs included
- Insert-adjustable caster blocks (0, +/-1, +/-2 degree inserts)
- Forward and rear motor positions for weight bias tuning
- Adjustable battery holder with thumb tabs
- 2.5mm thick tapered 7075-T6 aluminum chassis with 10° kickup
- Molded ring and pinion gears included
- Aluminum center-mounted servo mount
- Two rear wing mount heights included
- 7-inch rear wing
- Low-profile body with classic RC10 livery
- Shock tower covers front and rear
- 3.5mm turnbuckles and ball cups
- 13mm big-bore shocks
Performance Benefits
- True 4WD drivetrain delivers maximum traction and control
- Height-adjustable gearboxes optimize efficiency for any track
- Long-arm suspension improves corner speed and stability
- Reduced bump steer for tighter, more consistent lines
- Tunable chassis flex characteristics via adjustable bracing
- Multiple motor positions enable precise weight bias tuning
- Improved departure angle for aggressive jumping
- Enhanced aerodynamics with low-profile body design
Race-Ready Components
- 7075-T6 aluminum chassis for strength and rigidity
- 13mm big-bore shocks for consistent damping
- Premium composite plastics throughout
- RC10 Classic-inspired aluminum components
- Precision-molded drivetrain gears
Usage Notes
The RC10B84D Classic Kit is designed for competitive 4WD buggy racing on dirt, clay, and low-grip surfaces. This kit requires assembly and electronics selection, making it ideal for intermediate-to-advanced racers. Best suited for club-level through national-level competition. The "D" designation indicates dirt-specific tuning with the ball differential setup.
Technical Specs
-
Scale: 1/10
-
Drivetrain: 4WD
-
Length: 395mm (15.55 in)
-
Chassis: 2.5mm 7075-T6 Aluminum with 10° Kickup
-
Internal Gear Ratio: 2.50:1
-
Shocks: 13mm Big-Bore
-
Battery: 2S LiPo Shorty
-
Surface: Off-Road (Dirt, Clay, Low-Grip)
-
Format: Kit (Unassembled)
-
Brand: Team Associated
What's Included
- RC10B84D Classic 1/10 scale 4WD buggy kit (unassembled)
- 2.5mm 7075-T6 aluminum chassis
- Molded height-adjustable gearboxes (front, rear, +2 rear)
- 13mm big-bore aluminum shocks
- Shock tower covers front and rear
- Standard and HRC rear hubs
- Insert-adjustable caster blocks with all inserts
- Low-profile polycarbonate body (clear)
- 7-inch rear wing with dual mount heights
- Decal sheet with RC10 Classic livery
- Assembly hardware and instruction manual
Needed to Complete
- 2-channel radio system (transmitter and receiver)
- Steering servo
- Electronic Speed Controller (ESC)
- 540-size electric motor
- Pinion gear
- 2S LiPo shorty battery
- Compatible battery charger
- 1/10 off-road wheels and tires
- Polycarbonate body paint
- Silicone shock and diff fluids
- Assembly tools
Summary
The Team Associated RC10B84D Classic Kit combines legendary RC10 heritage with modern race engineering for championship-caliber dirt racing performance. With height-adjustable gearboxes, long-arm suspension, adjustable chassis bracing, and classic-inspired styling, this 4WD buggy delivers razor-sharp handling and podium-ready capability for serious competitors who demand the best.
