Overview
The Bat-Safe XL LiPo Battery Charging Safe Box is the ultimate fire-resistant charging and storage solution for serious RC hobbyists, FPV pilots, and anyone who works with high-capacity lithium batteries. Built with double-walled insulated steel construction and an integrated flame arrestor system, this extra-large enclosure dramatically reduces the risks associated with LiPo and Li-Ion battery charging. With capacity for up to 500Wh of battery storage, the Bat-Safe XL can safely accommodate four 6S 5000mAh LiPo batteries simultaneously.
Lithium battery fires are a real concern in the RC community, and the Bat-Safe XL provides unmatched protection for your home, workshop, and family. The innovative flame arrestor not only contains fire in the unlikely event of thermal runaway but also filters harmful smoke and soot to minimize damage to your surroundings. Whether you're charging racing packs, large FPV batteries, or multi-battery setups, the Bat-Safe XL delivers peace of mind with CE-certified materials and proven fire containment engineering. This unpainted industrial version offers a rugged, functional appearance perfect for workshop environments.
Key Features
- Double-walled steel construction with non-flammable insulation
- Integrated flame arrestor for fire containment and suppression
- Smoke and soot filtering system
- Extra-large 500Wh battery capacity
- CE-certified safety materials
- Removable internal charger stand
- Integrated carrying handle for portability
- Easy-opening lid with secure locking latch
- Fireproof wire routing ports
Performance Benefits
- Contains fire and intense heat from battery failures
- Filters smoke and soot to protect surrounding areas
- Accommodates multiple batteries for simultaneous charging
- Provides safe long-term lithium battery storage
- Reduces fire hazard risks during unattended charging
- Protects property and loved ones from battery fire damage
Usage Notes
- Place on a stable, heat-resistant surface during charging
- Due to the XL depth, standard balance wires are often too short
- Long balance wire set (BAFXLWIRESET) strongly recommended
- Two long wire sets may be needed for multi-battery charging
- Always charge batteries within manufacturer specifications
- Follow all standard LiPo charging safety procedures
- Ideal for RC cars, trucks, drones, FPV, and aviation applications
Technical Specs
-
Maximum Battery Capacity: 4× 6S 5000mAh LiPo (500Wh total)
-
Interior Dimensions: 9.5 × 6.5 × 14.5 in (240 × 165 × 380mm)
-
Exterior Dimensions: 12 × 9 × 17.5 in (305 × 230 × 445mm)
-
Weight: 8 lbs / 3.7 kg
-
Material: Double-wall steel sheet with non-flammable insulation
-
Certification: CE certified materials
-
Finish: Unpainted industrial
What's Included
- (1) Bat-Safe XL LiPo Battery Charging Safe Box - Unpainted
- (1) Removable internal charger stand
Note: Balance wire extensions sold separately (BAFXLWIRESET recommended)
Summary
The Bat-Safe XL is the largest and most capable fire-resistant LiPo charging solution available, offering 500Wh capacity for multi-battery charging and storage. With proven double-wall steel construction, integrated flame arrestor, and CE-certified materials, this XL enclosure provides maximum protection for high-capacity battery charging operations. Essential for serious RC racers, FPV pilots, and anyone who values safety when working with lithium batteries.
