ESC & Motor Combo Overview:
Enhance your RC experience with the Castle Sidewinder SW4 Waterproof 1/10 ESC/Motor Combo! Built upon Castle's popular Sidewinder 1/10 series, this first-of-its-kind ESC utilizes CRYO-DRIVE technology for increased thermal performance. Keep your cool for longer runs and more power! Perfect for short course, on road, monster truck, and rock crawler applications with the right motor. Upgrade to the Sidewinder 4 now!
This combo includes a Sidewinder 4 ESC and 1412-3200kV sensored motor. The 1412-3200kV sensored motor is ideal for 1/10 scale 2WD and 4WD SC Trucks, Monster Trucks and rock racers vehicles and 1/10 scale monster trucks up to 15lbs. It is a cool running torque animal for lighter 1/10th scale 2WD stadium trucks and buggies running up to 2-3S LiPo.
Sidewinder SW4 Features:
- 2S-3S LiPo with vehicles up 6.5 lbs with battery, ready-to-run
- Smooth Sensorless and sensored motor operation
- Waterproof design ESC and splash resistant 30MM fan
- Powerful 5.5 volts fixed, 8 amps Peak BEC
- Convenient transmitter programming for nine common adjustable settings
- LED error codes for common error conditions
- Full compatible with the Castle Link Programming Suite to modify settings and download software updates available via Windows-based Castle Link software and USB adapter (sold separately), or the Castle Link iOS App and a B-LINK Adapter. (sold separately)
- Proudly designed, assembled and supported in Olathe, KS USA
- Backed by Castle Creations' 1-year Warranty
1412-3200kV MOTOR Features:
- Redesigned stator and rotor assemblies to improve magnetic flux
- Reduced magnetic cogging, producing less residual drag brake
- Increased efficiency, resulting in lower temperatures and longer run times
- Smoother start-up, reducing cogging or stuttering when starting from a stop
- Rebuildable design allows replacement of front end bell/bearing assembly or rotor/shaft assembly
- High-Strength Kevlar wrap and 180C grade neodymium sintered magnets
- Oversized NMB bearings and high-temperature, high-purity copper windings
- High performance 0.2mm steel lamination stacked stator
- Oversized, low-resistance, gold-plated solder tabs
- Sensor board with high quality temperature stabilized sensors
- T6 aluminum CNC-Machined front/rear end bell
- Proudly designed and supported in Kansas, USA
Specifications:
- ESC:
-
Length: 2.08" (52.92mm)
-
Width: 1.5" (38.05mm)
-
Height: 1.28" (32.56mm)
-
Weight: 2.26oz (64g)
-
Input voltage range: 2-3S LiPo
-
BEC: 5.0V/2A Fixed
-
On/Off Switch: Yes
-
Cooling Fan: Factory equipped 30mm fan
-
Connector: 4mm Female bullets for motor connection
- Motor:
-
Application: 1/10 scale 2WD/4WD SC & Monster Trucks up to 15lbs
-
Input Voltage Range: 2-4S LiPo (3S Max with included Sidewinder 4)
-
Kv Rating: 3200kV
-
Max. RPM: 75.000
-
Diameter: 36mm
-
Length: 62.5mm
-
Shaft Size: 15mm (Length), 3.17mm (Diameter)
-
Weight: 9.4oz (265.4g)
-
Mounting Hole Specifications: (Holes) 3mm / (Spacing) 25mm
-
Connectors: 4mm Male Castle Bullet Connectors
NOTE:
- Although Sidewinder 4 is waterproof, it is not intended for operation while completely submerged in liquid. They can corrode when exposed to corrosive materials, such as salt water. Always rinse the ESC with clean water after exposure to corrosives or dirt.
Includes:
- (1) Sidewinder SW4 1/10 ESC
- (1) 1412-3200kV Brushless Sensored Motor
- (1) Coupon for free Castle Link USB
