Overview
The Kyosho Fantom PZF T-33 Kit brings a legendary 1980s 1/12 electric on-road racer back as a kit. Back then, 4WD ladder-chain cars battled agile 2WD cars with 3-point suspension. The PZF T-33 combines both: 4WD traction with 3-point suspension.
It's the first time the Plazma Phantom has been sold as a kit. Newly developed parts give it better performance than the original-era cars.
Key Features
- Ladder-chain 4WD system for high traction
- Carbon chassis and upper plate for high rigidity
- Kingpin coil-type front suspension
- Dial-adjustable oil dampers for quick setup changes
- Ball differential with adjustable tension
- Pre-mounted, trued tires on black wheels and reproduction T-33 body
Performance Benefits
- 4WD grip with sharp, precise handling
- Metal ball-connect suspension joints with O-rings for roll control
- Easy setup changes for different track conditions
- Kyosho quotes approx. 55km/h and 23-minute run time with a Le Mans 480G motor
Usage Notes
- Requires 2-channel radio, ESC, 540-class motor, LiPo battery and charger
- Body is unpainted – paint sold separately
- Transmitter batteries sold separately
Technical Specs
-
Brand: Kyosho
-
Item No.: 30640
-
Scale: 1/12
-
Drive: 4WD ladder chain, electric
-
Length: 353mm
-
Width: 172mm
-
Height: 86mm
-
Wheelbase: 201–202mm (adjustable)
-
Tread (F/R): 137mm / 133mm
-
Tires (F/R): 48 x 23mm / 53 x 35mm
-
Gear Ratio: 3.38:1
-
Weight: Approx. 900g (with recommended battery)
-
Motor: 540 class (sold separately)
What's Included
- (1) Fantom PZF T-33 chassis kit
- (1) Set of pre-glued tires on wheels
- (1) Unpainted T-33 body with decals
- (1) Set of wrenches, shock tools, shock oil and assembly hardware
Summary
- Legendary 1/12 on-road racer, sold as a kit for the first time
- 4WD ladder chain combined with 3-point suspension
- Carbon chassis with adjustable ball diff and dampers
