Overview
The Kyosho Lazer ZX-7.5 represents the cutting edge of competitive 1/10 scale 4WD electric buggy racing. Building on the proven ZX7 platform, this kit features comprehensive refinements including updated chassis design, optimized weight distribution, and race-tuned components capable of World Championship-level competition.
The updated A7075-T6 aluminum main chassis has been reduced from 2.5mm to 2.0mm thickness for lighter weight and improved flex characteristics. The repositioned center bulkhead shifts weight balance 7mm forward compared to the ZX7 for improved traction and stability.
Key Features
- A7075-T6 aluminum chassis (2.0mm)
- Repositioned center bulkhead (+7mm forward)
- 13mm big bore aluminum oil shocks with resin caps
- 4mm thick carbon fiber shock towers
- Geared center differential
- Floating servo mount layout
- Adjustable caster (7°, 10°, 13°)
- Sintered steel differential gears
- Front upper plates (Type A and Type X included)
Performance Benefits
- Improved grip from chassis flex
- Better front-to-rear balance
- Smoother steering characteristics
- Enhanced durability in front/rear diffs
- Multiple setup options for various tracks
Usage Notes
- Suitable for carpet, artificial turf, and dirt tracks
- Competition-level racing platform
- Designed for shorty LiPo batteries
Technical Specs
-
Scale: 1:10
-
Drive: 4WD
-
Power Source: Electric (2S LiPo)
-
Length: 385mm
-
Width: 248mm
-
Height: 145mm
-
Wheelbase: 278mm
-
Tread: F: 210mm / R: 200mm
-
Weight: ~1,650g
What's Included
- Lazer ZX-7.5 unassembled kit
- Clear polycarbonate body
- Rear wing
- Aluminum oil shocks
- Carbon shock towers
- Front upper plates (Type A and Type X)
- Hex wrenches and cross wrench
- Teflon grease
Needed to Complete
- 2-3 Channel Radio System
- Steering Servo
- Electronic Speed Controller
- 540 Motor and Pinion
- 2S LiPo Shorty Battery
- Battery Charger
- Tires and Inserts
- Shock Oil and Diff Oil
- Body Paint
- Assembly Tools
Summary
The Kyosho Lazer ZX-7.5 delivers World Championship-caliber performance with comprehensive updates to the proven ZX7 platform. From the optimized chassis flex to adjustable suspension geometry, every detail is engineered for competitive racing at the highest level.
