Overview
The SRT low-profile HV brushless servo delivers 23kg of torque at 0.065 second transit speed on 8.4V in a low-profile case. This version ships with a short 80mm lead, which keeps wiring tidy when the receiver sits close to the servo.
The SRT Low servo provides a 180 degree limit angle range of motion and position control for your project. It is well suited to 1:10 on-road applications, and it is also a good match for animatronics and scale projects where a low case height and precise positioning matter.
Key Features
- Brushless motor for higher efficiency and longer service life
- High voltage (HV) capable operation
- 23kg torque at 8.4V
- 0.065 second transit speed at 8.4V
- Low-profile case height
- Short 80mm lead length
- 180 degree limit angle range of motion
Performance Benefits
- Brushless internals hold their speed and torque more consistently than a brushed servo
- Fast transit speed gives crisp, immediate steering response
- Low-profile body drops the servo lower in the chassis for a better center of gravity
- Short lead avoids coiling excess wire in a tight touring car chassis
Usage Notes
- Run on an HV-capable receiver or BEC — confirm your electronics support 8.4V before powering up.
- Center the servo with the transmitter before installing the horn.
- Set steering endpoints in the transmitter to avoid binding the servo against the steering stops.
- Choose the 80mm lead version for a nearby receiver; a 180mm lead version is also available for remote mounting.
Technical Specs
- Brand: SRT
- Item No.: SRTBHX2S80MM
- Type: Low-profile HV brushless servo
- Torque: 23kg @ 8.4V
- Speed: 0.065 sec @ 8.4V
- Lead length: 80mm
- Range of motion: 180 degree limit angle
What's Included
- (1) SRT low-profile HV brushless servo with 80mm lead
Fitment
Compatible RC vehicles: 1:10 on-road RC cars and other builds that accept a low-profile servo, including scale rigs and animatronics projects. Verify servo bay dimensions and HV support before installing.
Summary
- 23kg / .065sec brushless performance at 8.4V
- Low-profile case for low mounting in 1:10 on-road chassis
- Short 80mm lead for clean, close receiver wiring
- Also suited to scale and animatronics use
