Overview
The Tamiya Plasma Edge II Gun Metal is an exciting 1/10 scale 4WD electric off-road buggy kit featuring a stylish factory pre-painted gun metal polycarbonate body. Built on the proven TT-02B buggy chassis, this Limited Edition version delivers aggressive styling with reduced finishing time. Designed for beginners and casual off-road drivers, the Plasma Edge II offers durable construction, stable handling, and excellent upgrade potential.
The TT-02B is a dedicated off-road buggy chassis that offers hassle-free assembly and maintenance, as well as superb controllability. Its shaft-driven 4WD system provides confident traction on dirt, gravel, and grass, while the balanced chassis layout ensures predictable handling. With CVA oil shock units, high-grip square spike tires, and a wide range of available hop-up options, the Plasma Edge II is ready for serious off-road action.
Key Features
- 1/10 scale R/C model assembly kit (Length: 370mm, Width: 250mm, Height: 160mm)
- Limited Edition factory pre-painted PS-23 Gun Metal body and wing
- Proven TT-02B shaft-driven 4WD buggy chassis
- Bathtub-type skid-shaped frame for durability
- 4-wheel independent double wishbone suspension with long arms
- White CVA oil shock units for superior handling
- Sealed front/rear gearboxes with 4-bevel differentials
- Includes 540 Torque Tuned motor
- Includes TBLE-02S ESC (brushless and brushed compatible)
- 4 gear ratio options available
Chassis Features
- Skid-shaped bathtub frame with low center of gravity
- Longitudinal battery and R/C mechanism placement
- Identical left/right suspension arms and uprights
- Sealed gearboxes prevent dust infiltration
- Easy top removal for quick maintenance
- Receiver case and motor cover protect electronics
- Dogbone drive shafts for reliable power transfer
- Wide tread: 217mm front, 208mm rear
Performance Benefits
- Shaft-driven 4WD delivers excellent off-road traction
- CVA oil shocks provide smooth, controlled suspension
- Long suspension arms improve bump absorption
- 4-bevel differentials ensure smooth cornering
- Square spike tires grip on loose surfaces
- Torque Tuned motor provides enhanced acceleration
- TBLE-02S ESC supports brushless motor upgrades (21.5T limit)
Usage Notes
- Pre-painted gun metal body and wing ready to assemble
- Ideal for dirt, gravel, grass, and loose surfaces
- 4 gear ratios: 10.71:1 standard, plus 3 options with pinion changes
- Ball bearings recommended as upgrade from stock bushings
- Wide range of TT-02B hop-up options available
- ESC compatible with brushed motors (23T limit) and brushless (21.5T limit)
Fitment
Compatible RC vehicles: Tamiya TT-02B.
Technical Specs
| Specification |
Details |
| Scale |
1/10 |
| Length |
370mm |
| Width |
250mm |
| Height |
160mm |
| Wheelbase |
266mm |
| Tread (Front/Rear) |
217mm / 208mm |
| Tire Width/Diameter (Front) |
32mm / 82mm |
| Tire Width/Diameter (Rear) |
41mm / 82mm |
| Chassis |
TT-02B Bathtub Frame |
| Drive Type |
Shaft-driven 4WD |
| Differentials |
Front/Rear 4-bevel |
| Suspension |
4-wheel double wishbone (long arms) |
| Dampers |
White CVA oil shock units |
| Motor |
540 Torque Tuned (included) |
| ESC |
TBLE-02S (brushless/brushed compatible) |
| Gear Ratio |
10.71:1 (3 additional ratios available) |
What's Included
- Tamiya TT-02B buggy chassis kit
- Pre-painted PS-23 Gun Metal polycarbonate body
- Pre-painted gun metal rear wing
- White CVA oil shock units
- Star dish wheels (fluorescent yellow on standard version)
- Square spike tires (front and rear)
- 540 Torque Tuned motor
- TBLE-02S Electronic Speed Controller
- Receiver case and motor cover
- Marking stickers
- Instruction manual
Needed to Complete
- 2-channel radio system
- Steering servo
- 7.2V battery pack (NiMH recommended)
- Battery charger
- AA batteries for transmitter
Summary
The Tamiya Plasma Edge II Gun Metal Limited Edition is the perfect entry point into competitive off-road RC. With its stunning pre-painted gun metal body, advanced TBLE-02S ESC supporting brushless upgrades, and proven TT-02B chassis, this kit offers exceptional value and performance. Whether you're hitting backyard dirt tracks or club circuits, the Plasma Edge II delivers reliable 4WD traction and exciting off-road action.
