Description
Overview
The Tamiya M-07R Chassis Kit represents the ultimate evolution of front-wheel-drive RC racing technology. This limited edition kit takes the revolutionary M-07 Concept platform and pairs it with a carefully selected range of premium option parts chosen by the Tamiya Racing Factory (TRF) team specifically for competitive racing. For drivers seeking race-ready performance straight from the box without the need to individually select and purchase hop-up parts, the M-07R delivers exceptional value and championship-caliber specifications.
This chassis-only kit is designed for serious racers who want to pair their own preferred M-chassis body with a competition-ready platform. The included TRF-selected upgrades include Special Dampers with hard black coating, carbon fiber battery holders, high-traction lower deck, reinforced suspension components, titanium-coated shafts, and aluminum drivetrain parts. Every component has been chosen to maximize performance, durability, and handling precision right out of the box.
Key Features
- Limited edition race-focused M-07R chassis kit
- TRF (Tamiya Racing Factory) selected option parts included
- TRF Special Dampers with hard black coating
- Carbon fiber battery holder unique to this kit
- High-traction lower deck for improved chassis rigidity
- Reinforced C Parts (Uprights) and D Parts (Suspension Arms)
- Titanium-coated suspension shafts
- Full ball bearing set included
- Rear stabilizer for balanced cornering
Chassis Features
- M-07R front-wheel-drive competition chassis
- Fully independent double wishbone suspension
- TRF Special Dampers (aluminum, oil-filled)
- 33mm double cardan joint shafts for efficient power delivery
- Aluminum cup joints (TA06 compatible)
- Hard fluorine-coated 0.6 aluminum 20T pinion gear
- ?2.6mm titanium-coated suspension shaft set
- 46mm titanium-coated suspension shafts
- 3x106mm aluminum turnbuckle shaft
- Clamp-type aluminum wheel hubs (5mm thick)
TRF Racing Upgrades Included
- M-07 Concept High-Traction Lower Deck (54812)
- TRF Special Damper Hard Black Coating (42102)
- M-07 Concept Reinforced C Parts Uprights (54810)
- M-07 Concept Reinforced D Parts Suspension Arms (54811)
- 33mm Double Cardan Joint Shaft 2pcs (42312)
- Clamp Type Aluminum Wheel Hub 5mm Thick (53823)
- Aluminum Cup Joint for TA06 Gear Diff (54532)
- Hard Fluorine Coated Aluminum Pinion 20T (53509)
- Titanium Coated Suspension Shaft Set (53917)
- 46mm Titanium Coated Suspension Shafts (53851)
- 3x106mm Aluminum Turnbuckle Shaft (54756)
Performance Benefits
- Race-ready setup eliminates time selecting individual upgrades
- TRF Special Dampers provide consistent, smooth handling
- Carbon fiber battery holder reduces weight while adding strength
- High-traction lower deck increases chassis rigidity
- Reinforced suspension components boost durability under stress
- Titanium-coated shafts reduce friction and wear
- Double cardan shafts deliver efficient power transfer
- Full ball bearings ensure smooth operation throughout
Usage Notes
- Chassis-only kit - body set sold separately
- Compatible with M-chassis body sets
- Designed for competitive on-road racing
- Motor, ESC, and electronics sold separately
- Compatible with 2S LiPo batteries (7.2-7.4V)
- Requires M-chassis body set and Tamiya PS paint
Technical Specs
- Scale: 1/10
- Length: 322-332mm (varies with body)
- Width: 164mm
- Wheelbase: 239mm
- Drivetrain: Front-wheel Drive
- Gear Ratio: 7.22:1 (lowest)
- Standard Pinion: 20T
- Suspension: Fully independent double wishbone
- Dampers: TRF Special (aluminum, oil-filled)
- Chassis: M-07R
What's Included
- M-07R chassis kit with all TRF-selected upgrades
- Carbon fiber battery holder
- TRF Special Dampers (hard black coating)
- High-traction lower deck
- Reinforced uprights and suspension arms
- 33mm double cardan joint shafts
- Aluminum cup joints
- Titanium-coated suspension shafts
- Aluminum wheel hubs and turnbuckle
- Hard fluorine-coated aluminum pinion gear
- Full ball bearing set
- Rear stabilizer
- Assembly instruction manual
Needed to Complete
- 2-channel radio transmitter and receiver
- Steering servo
- 540-size motor
- Electronic Speed Controller (ESC)
- 7.2-7.4V battery pack
- Compatible battery charger
- M-chassis body set
- Tamiya PS polycarbonate paint
Summary
The Tamiya M-07R Chassis Kit is the ultimate choice for competitive front-wheel-drive RC racing. This limited edition release packages the refined M-07 platform with a comprehensive selection of TRF-approved racing upgrades, delivering championship-level performance straight from the box. The included premium components—from TRF Special Dampers to titanium-coated shafts and carbon fiber battery holders—represent significant value compared to purchasing each upgrade separately. For racers who demand precision, durability, and competitive advantage in M-chassis competition, the M-07R provides a race-ready foundation that's engineered to win.
