Overview
These Tekno RC shock piston blanks are precision molded with a 15.8mm diameter and a flat top and flat bottom profile. Each blank carries 16 dimples that act as drilling guides, so you can create your own hole pattern and size instead of being limited to off-the-shelf pistons.
Custom pistons give the serious racer full control over shock damping across the stroke. Tekno RC lists these blanks for its 16mm-bore 1/8 scale shocks, and they are a good way to experiment with damping without buying multiple pre-drilled sets. They require the TKR1267 washer, the larger washer Tekno first released in the ET48 2.2 and NT48 2.2.
Key Features
- Genuine Tekno RC shock piston blanks
- Precision molded construction
- 15.8mm diameter for 16mm bore shocks
- Flat/Flat profile
- 16 dimples to guide drilling
Performance Benefits
- Tailor damping to your track and driving style
- Consistent molded blanks give repeatable results
- Lets you try hole counts and sizes not offered pre-drilled
- Fresh pistons remove slop from worn shock internals
Usage Notes
- Drill each blank on a drill press or piston jig for accurate, square holes
- Deburr holes and keep a matched set for each axle
- Rebuild shocks with fresh oil after changing pistons
- Requires TKR1267 washers (sold separately)
Technical Specs
- Brand: Tekno RC
- Item No.: TKR6134
- Type: Shock piston blanks
- Profile: Flat/Flat
- Diameter: 15.8mm
- Dimples: 16
- Construction: Precision molded
- Requires: TKR1267 washer
- Scale: 1/8
- Country of Origin: Taiwan
What's Included
- (1) Tekno RC shock piston blank set as packaged by Tekno RC
Fitment
Compatible RC vehicles: Tekno RC EB48 2.0, EB48 2.1, EB48 2.2, ET48 2.0, ET48 2.2, NB48 2.0, NB48 2.1, NB48 2.2, NT48 2.0 and NT48 2.2 1/8 vehicles.
Summary
- Genuine Tekno RC 15.8mm molded piston blanks
- Flat/Flat profile with 16 drilling dimples
- Build custom damping for 16mm bore shocks
- Fits Tekno RC EB48 2.0, EB48 2.1 and EB48 2.2 and more
